SPIRE

Monkeyfab Spire

Ultra silent 3D printer made for labor

Design. Print. Deliver

  • WiFi server onboard.

    Connect your printer to a local WiFi network and print remotely. A dedicated web interface provides easy control and access to every detail.

    From g-code upload and configuration to print control, everything on your favourite device.

    Requires accessible WIFI network.

  • Compact, integrated printhead.

    Light, lit and robust. Integrated print effector including all you desire and a bit more, for expansion.

    • Hotend cooling fan.
    • Print cooling blower fan.
    • 6 star white LEDs.
    • 3 pin connector for an optional IR probe.
    • Hotend with 30W cartridge heater and thermistor.

  • Quick release locking build plate.

    Change your plate in seconds and start new job. Spire workplate provides you a non blocking printing workflow and is fun to use. Use your favourite adhesive stuff, and go.

    And yes, it’s heated, ofcourse!

  • Backlash free magnetic joints.

    Precise and smooth positioning, with a snap!

  • Light and stiff carbon rods.

    Light and stiff carbon rods, flexible to use, rigid where it’s due.

INDUSTRIAL SOLUTIONS

Monkeyfab Spire Cluster. Maximize efficiency.

Quick release heated bed. Monkeyfab Spire quick swap heated bed platform provides a solution for efficient and clean buildplate changing.
Integrated printhead module. Monkeyfab Spire integrated printhead module. Takes a few seconds to change. Equipped with LEDs, fans and space for custom changes.
Hidden filament chamber. Hidden filament chamber.
Your material reel is safe from dust, for reliable long prints and filament free desktop landscape.
Hidden filament chamber. Hidden filament chamber.
Your material reel is safe from dust, for reliable long prints and filament free desktop landscape.
Backlash free magnetic joints. Light and stiff carbon rods, flexible to use, rigid where it's due.
Precise and smooth positioning, with a snap!
Precise steppers. High precision 0.9 degree stepper motors provide higher resolution so important in delta printers.
32 bit controller and high end Trinamic drivers keeps them at speed.
WiFi server onboard. Control Spire using your favourite device with a web browser.
From g-code upload and speed knob to firmware reflash, full access at your fingertips. Requires accessible WIFI network.
WiFi server onboard. Control Spire using your favourite device with a web browser.
From g-code upload and speed knob to firmware reflash, full access at your fingertips. Requires accessible WIFI network.
FEATURES
  • WIFI connectivity
  • Automatic calibration
  • Easy change integrated printhead module
  • Quick release heated print platform
  • Magnetic backlash free joints
  • Hidden filament chamber
  • Removable polycarbonate shields (optional)
PHYSICAL
  • Size: 300 x 300 x 575 mm
  • Weight: 10kg
  • Box size: 370 x 370 x 720 mm
  • Box weight: 12kg
ELECTRICAL
  • Power consumption: 120W peak / 70W avg.
  • Power supply: 110 – 220 VAC input / 19V 6.3 A output
PRINTING
  • Max. print volume: cylinder 150 x 165 mm
  • Max. hotend temperature: 262 C
  • Max. platform temperature: 120 C
  • Material (filament) diameter: 1.75 mm
  • Nozzle diameter: standard 0.4mm nozzle
  • Min. recommended layer height: 0.05mm
  • Positioning repeatability: 0.07mm
ELECTRONICS / CONTROLLER
  • Duet WIFI controller
  • 32 bit ARM processor
  • Trinamic high precision stepper drivers
  • Network connectivity
  • Easy to use
  • High level of control
MATERIALS
  • ABS
  • PET
  • Nylon
  • PLA
  • PHA
  • HIPS
  • Hard elastomers
  • Other experimental materials
SOFTWARE
  • Firmware: RepRapFirmware by David Crocker
  • Recommended printer host: Duet Web Control by Christian Hammacher
  • Recommended slicer: KISSlicer
POWER TO THE CREATORS

Make massive models. Smooth and reliable.
